Plastic Conical Double Screw Extruder Machine China USD 10000 - USD 80000

Zhangjiagang Plummytech Imp&Exp Co.,Ltd is a company and manufacturer of Plastic Conical Double Screw Extruder Machine in China Plastic Conical Double Screw Extruder Machine China,Conical Double Screw extruder China,double screw extruder China,

product details

Plastic Conical Double Screw Extruder Machine Technical Data

SJSZ series conical twin screw extruder is a kind of efficient extrusion equipment.It is mainly composed by force feeder, soft plasticization screw and barrel, high precision gearbox, exhaust system. It performs stability and can make the melt extrude well at lower temperature.
Match our company manufactured moulds and auxiliary machinery, it can be directly to produce plastic products,such as plastic pipes, sheets, profiles, pellets, etc.
The extruder installs vacuum exhausting and quantitative feeding device.The barral is equipped with cast aluminum heater which is high thermal efficiency and also configured blower cooling machine to maintain the temperature.

Model	SJSZ51	SJSZ55	SJSZ65	SJSZ80	SJSZ92	more models based on your requirements
Screw diameter(mm)	51/105	55/110	65/132	80/156	92/188
Max speed(rpm)	40	38	38	37	36
Motor power(kw)	18.5	22	37	55	90
Output(kg/h)	80-100	100-150	150-250	250-380	380-700
Centre height(mm)	1050	1050	1050	1050	1100
Net weight(kg)	3000	3500	4000	5500	8000
LWH(m)	3.61.12.1	3.61.12.1	4.21.52.4	4.71.52.4	61.62.5
